8-Bit MCU
8-bit RISC Architecture Series MCU Selection Table:
|
Part No. |
Package |
Voltage |
OTPROM |
FlashROM |
RAM |
EEPROM |
I/O |
ADC |
RTC |
Timer |
PWM |
Int. |
OSC |
OSC Fre. |
|
UP8E0106 |
SOP8/SOT23-6 |
2.0V~5.5V |
- |
1K*14 |
64*8 |
128*8 |
5+1 |
- |
NO |
8bit*2 |
- |
4 |
IRC |
16M/8M/4M/32K |
|
UP8E03C3 |
SOP8/16/TSSOP20 |
2.0V~5.5V |
- |
3K*14 |
256*8 |
128*8 |
18 |
8+1(12bit) |
YES |
8bit*3 |
4+3 |
5 |
IRC/XT |
16M/8M/4M/32K |
|
UP8E1214 |
SOP8/14/16 |
2.0V~5.5V |
- |
2K*14 |
128*8 |
128*8 |
14 |
7+1(10bit) |
YES |
8bit*3 |
3+3 |
5 |
IRC/XT |
16M/8M/4M/32K |
|
UP8E1214M |
SOP16 |
2.0V~5.5V |
- |
2K*14 |
128*8 |
128*8 |
11+ 2CH 1.2A moto driver |
6+1(10bit) |
YES |
8bit*3 |
3+3 |
5 |
IRC/XT |
16M/8M/4M/32K |
|
UP8E1213 |
SOP20/TSSOP20 |
2.0V~5.5V |
- |
3K*14 |
256*8 |
128*8 |
18 |
8+1(12bit) |
YES |
8bit*3 |
4+3 |
5 |
IRC/XT |
16M/8M/4M/32K |
|
UP8E1215 |
SOP28 |
2.0V~5.5V |
- |
8K*16 |
616*8 |
128*8 |
26（share with Touch） |
26 |
YSE |
8bit*1+12bit*3+16bit*3 |
4+2 |
5 |
IRC/XT |
16M/8M/4M/32K |
|
UPT8F1816B/C |
SOP16/SSOP24 |
2.0V~5.5V |
- |
8K*16 |
256*8 |
Share Flash |
14/22 |
9/10CH(12bit) |
YES |
16bit*1+8bit*1 |
2/6*10bit |
4 |
IRC |
21M/16M/8M/4M/1M/32K |
|
UPT8F1816BM/CM |
SOP16/SSOP24 |
2.0V~5.5V |
- |
8K*16 |
256*8 |
Share Flash |
11/19+2CH 1.2A moto driver |
8CH(12bit) |
YES |
16bit*1+8bit*1 |
- |
4 |
IRC |
21M/16M/8M/4M/1M/32K |
|
UPT8F1816GM |
QFN4*4-28L |
2.0V~5.5V |
- |
8K*16 |
256*8 |
Share Flash |
19+2*1.2A Moto driver+1A charge |
10CH(12bit) |
YES |
16bit*1+8bit*1 |
6*10bit |
4 |
IRC |
21M/16M/8M/4M/1M/32K |
|
UPT8PN50B |
SOP8/SOT23-6 |
2.0V~5.5V |
0.5K*14 |
- |
32*8 |
NO |
5+1 |
- |
NO |
8bit*1 |
- |
3 |
IRC |
16M/8M/4M/32K |
|
UPT8PN51C/F |
SOP8/SOT23-6 |
2.0V~5.5V |
1K*14 |
- |
48*8 |
NO |
6 |
- |
YES |
8bit*2 |
3 |
7 |
IRC/XT |
16M/8M/4M/32K |
|
UPT8PN62C |
SOP8/14/16 |
1.7V~5.5V |
2K*14 |
- |
128*8 |
NO |
14 |
11+1(12bit) |
YES |
8bit*4 |
3 |
16 |
IRC/XT |
16M/8M/4M/32K |
|
UPT8PN62AE |
SOP14 |
1.7V~5.5V |
2K*14 |
- |
128*8 |
256*8 |
12 |
11+1(12bit) |
YES |
8bit*4 |
3 |
16 |
IRC/XT |
16M/8M/4M/32K |
8-bit Enhanced 1T Tiny 8051 Core MCU Selection Table:
|
Part No. |
Package |
Voltage |
FlashROM |
RAM |
TouchKey |
I/O |
ADC |
OP |
Timer |
PWM |
UART |
I2C |
SPI |
Int. |
OSC Fre. |
LED Driver |
Temp. |
|
UPT8F3230/31 |
SOP16 |
2.0V~5.5V |
32K+8K |
256+1.5K |
13 |
14 |
14CH(12bit) |
1 |
3 |
8*16bit |
2 |
1 |
1 |
9 |
32M |
√ |
-40~105°C |
|
UPT8F3231 |
SOP20/QFN20 |
2.0V~5.5V |
32K+8K |
256+1.5K |
17 |
18 |
18 CH(12bit) |
1 |
3 |
8*16bit |
2 |
1 |
1 |
9 |
32M |
√ |
-40~105°C |
|
UPT8F3230 |
SSOP24/QFN24 |
2.0V~5.5V |
32K+8K |
256+1.5K |
21 |
22 |
22 CH(12bit) |
1 |
3 |
8*16bit |
2 |
1 |
1 |
9 |
32M |
√ |
-40~105°C |
|
UPT8F3230 |
SSOP28/TSSOP28 |
2.0V~5.5V |
32K+8K |
256+1.5K |
25 |
26 |
26 CH(12bit) |
1 |
3 |
8*16bit |
2 |
1 |
1 |
9 |
32M |
√ |
-40~105°C |
|
UPT8F3230/31 |
SOP28 |
2.0V~5.5V |
32K+8K |
256+1.5K |
25 |
26 |
26 CH(12bit) |
1 |
3 |
8*16bit |
2 |
1 |
1 |
9 |
32M |
√ |
-40~105°C |
|
UPT8F3230 |
QFN4*4-28L |
2.0V~5.5V |
32K+8K |
256+1.5K |
25 |
26 |
26 CH(12bit) |
1 |
3 |
8*16bit |
2 |
1 |
1 |
9 |
32M |
√ |
-40~105°C |
